T-Motor Cine80A 80A 5S-12S FPV ESC AM32
Prices incl. VAT plus shipping costs
Free Shiping within Germany
In Stock
Delivery time appr. 1-3 workdays within Germany
- Order number: PM-7244
- Hersteller: T-Motor
- Artikelname: Cine80A-12S
- EAN: 4250902365974
About T-HOBBY Cine 80A 5-12S AM32 Cinelifter Drone ESC
Experience superior performance with the T-HOBBY Cine 80A 12S ESC. Its innovative design features a PCB with enhanced thermal conductivity and a double-sided heat sink, ensuring a remarkable 25% lower temperature compared to similar products at the same power level. With precise dead time tuning for heightened ESC response speed, a 3OZ six-layer PCB design to minimize wire loss, and compatibility with 12S voltage, this ESC delivers optimal efficiency for your FPV drone and cinematography needs.
Cine 80A 8S Hightlight:
The Cine 80A AM_32 5-12S single ESC is perfect for large cinelifters and up to 12S voltage.
Under 12S voltage, the 80A sustains output for 30S and the temperature drop of over 20℃ compared to similar products.
Weighing only 31.2g, it has power density of 92.3W/g a 51% increase compared to similar products. Accurate dead time turning, 3OZ six-layer PCB design to reduce wire loss.
Packing List Includes:
1x T-HOBBY Cine 80A 5-12S AM_32 ESC
2x Capacitor Boards
1x Signal Cable
2x Capacitor
Matching Guide:
Continuous 80A load
under 12S voltage, the 80A sustains output for 30S, exhibiting a temperature drop of over 20°C compared to similar products
Temperature comparison
Test conditions (48V, with heat sink)
Temperature comparison
Test conditions (48V, without heat sink)
High Power Density Ratio
Weighing only 31.2g, it has power density of 92.3W/g a 51% increase compared to similar products
Efficient PCB
Heat Dissipation Design
PCB thermal conductivity + double-sided heat sink design
resulting in a 25% lower temperature compared to similar products at the same power
Accurate Dead Time Tuning
Precise dead time tuning,enhanced ESC response speed
High copper thickness multi-layer PCB design
3OZ six-layer PCB design to reduce wire loss
- C80A 12S SPEC
Input Voltage：5-12S
BEC：None
Weight：32g
Current：80A
Peak Current：100A
Size：55x28x10mm
Firmware：AM32
Power Cable
Signal Cable
Capacitors
Capacitors Board
